PVC Tail Lift

Product Overview:

500kg Series Single-Cylinder Dual-Folding Built-In Tail Lift
Designed for compact and efficient performance, this tail lift is ideal for vehicles requiring space-saving solutions.

Availability:



Inquire

Model:
CD-QBTK05/105A

PVC Tail Lift 500Kg Tail Lift Single-Cylinder Folding Tail Lift Space-Saving Tail Lift PVC Loading Platform Zero-Tail Clearance tail gate Tail Lift with Two-Button Contro Customizable Tail Lift Folding Tail Lift for Small Trucks 500kg aluminum Tail Lift

Product Description

Features:

· Single-Cylinder Lift, Manual Folding: Compact and user-friendly design.

· Lightweight Construction: Features a PVC loading platform for reduced weight.

· Built-In Installation: Fits seamlessly under the vehicle, achieving zero-tail clearance without interfering with door operation or reversing.

· Patented Kashi Follow-Up Mechanism: Enables automatic tilting for smooth loading and unloading.

· Simple and Reliable Hydraulic System: Operated with just two buttons for ease of use.

· Customization Services Available：Lifting weight ranging from 500KG to 2000KG (not exceeding 2000KG) to suit specific requirements

Perfect for vehicles requiring space-saving solutions, this model combines innovation with practicality.

Specifications：

Model	CD-QBTK05/105A
Platform size	1600mm W×975mm H (customizable to fit your vehicle body)
Lifting capacity	500kg
Lifting Height	1050mm
Working Pressure	16MPa
Power Pack	12V / 24V（DC）
Lifting speed	80mm/s
Weight	200kg

PVC Tail Lift
